PRODUCT: 9" wide by 75-foot roll

• Developed for SIPs and panelized construction as a durable, all-weather vapor tight joint sealant
• Innovative hybrid synthetic rubber specially formulated to develop a strong bond with OSB and engineered wood products
• High initial tack for immediate bond
• Facing is thermally stable, smooth and conformable to irregular surface

• An air and vapor sealing tape for all types of construction
• Excellent adhesion to OSB, plywood, lumber, EPS foam, MgO, concrete, painted metal, most vinyl, PVC plastic and most common building materials (always test adhesion)
• Consult your design professional for proper location of vapor tape with SIP construction. Generally, the tape is installed on the outside of the panel in warm climates and on the inside in cold climates.

TECHNICAL DATA:

•100% Solids - No VOC’s
•Working temperature -40°F to 180°F (-40°C to 82°C)
•Application temperature 0°F to 120°F (-18°C to 49°C)
• Adhesion to OSB (tested to ASTM D-3330) 5.0#
• Adhesion to anodized aluminum (tested to ASTM D-3330) 6.6#
• Adhesion to house wrap (highly dependent on brand) • Adhesion to extruded PVC (ASTM D3330) 7.2#
• Adhesion to plywood (ASTM D3330) 6.1#
• Nail seal ability (Tested to AAMA 711-13) Pass
• Hydrophobic – will not absorb or attract moisture
• UV Stability – 6 months
• Resists common mold growth
• Vapor Tight • Shelf life 24 months from date of manufacture

INSTRUCTIONS:
For proper adhesion, bonding surface must be dry and free of debris, dust, dirt, frost or ice. It is advisable to use a stiff brush or scraper to remove loose particles of OSB from the bonding surface prior to application. Always check adhesion and chemical compatibility with any new substrate.
• Gradually peel back the release liner and begin applying short sections using hand pressure and working from the center out to avoid wrinkles. Overlap the tape 2”-3” at the tape joints for a tight seal.
• Use a SIP-SEAL 45 Durometer Roller to work the tape into the surface and ensure that the edges are properly bonded.
• If tape does not adhere, additional site-specific measures should be taken to assure proper adhesion.
• Cut and overlap every 15’ or less
